Size Range:
Seamless:Outer Diameter: Φ3-Φ600mm;Wall Thickness: 0.5-100mm; Length:24000mm
Welded:Outer Diameter: Φ6-Φ1219mm;Wall Thickness: 0.3-45mm ;Length: 18000mm (Maximum)
Standards:ASTM A213;ASTM A269;ASTM A312;ASTM A632;ASME SA213;NFA 49-117;BS 10216
316 / 316L stainless steel pipe is used for pressure operations to move liquids or gases in water treatment, waste treatment, petrochemical, chemical and pharmaceutical industries. Structural applications include handrails, poles and support pipe for salt water and corrosive environments.
Mikayla steel Supply’s 316/316L stainless steel pipe meets industry standards and specifications. Our ASTM A312 and ASME SA312 stainless steel pipe is strong, durable, and suited for a wide range of applications.
Dimensional Tolerances
OD | OD Tolerance | Wall Tolerance |
≤ .500” | ± .005” | ± 10% |
.500”–1.500” excl | ± .005” | ± 10% |
1.500”–3.500” excl | ± .010” | ± 10% |
3.500”–5.500” excl | ± .015” | ± 10% |
ASTM A213;ASTM A269;ASTM A312;ASTM A632;ASME SA213;NFA 49-117;BS 10216
Typical Chemical Composition % (max values, unless noted) | |||||||||
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
316 | 0.08 | 2.0 | 0.75 | 0.045 | 0.03 | min: 16.0 | min: 2.0 | min: 10.0 | 0.10 |
316L | 0.03 | 2.0 | 0.75 | 0.045 | 0.03 | min: 16.0 | min: 2.0 | min: 10.0 | 0.10 |
MECHANICAL PROPERTIES:
Typical Room Temperature Mechanical Properties | |||||
Grade | Tensile Strength | Yield Strength 0.2% Offset KSI (min.) | Elongation % in 2ʺ(50.8 mm) | Hardness | Hardness |
316 | 75 | 30 | 40 | 217 | 95 |
316L | 70 | 25 | 40 | 217 | 95 |
